JIC-915
| SIZE | LOAD INDEX | SPEED INDEX | SECTION WIDTH (mm) | OUTER DIAMETER (mm) | GROOVE DEPTH |
|---|---|---|---|---|---|
| 175/65R14 | 82 | T | 177 | 584 | 8.1 |
| 175/70R13 | 82 | T | 177 | 576 | 8.1 |
| 185/60R14 | 82 | T | 189 | 578 | 8.3 |
| 185/65R14 | 86 | T | 189 | 596 | 8.3 |
| 185/65R15 | 88 | T | 189 | 621 | 8.3 |
| 185/70R14 | 88 | T | 189 | 616 | 8.3 |
| 195/55R15 | 85 | T | 201 | 595 | 8.3 |
| 195/60R15 | 88 | T | 201 | 615 | 8.3 |
| 195/60R16 | 89 | T | 201 | 640 | 8.3 |
| 195/65R15 | 91 | T | 201 | 635 | 8.3 |
| 205/50R17 | 89 | H | 214 | 638 | 8.3 |
| 205/60R16 | 92 | T | 209 | 652 | 8.3 |
| 205/65R15 | 94 | T | 209 | 647 | 8.3 |
| 205/70R15 | 96 | T | 209 | 669 | 8.3 |
| 215/55R18 | 95 | H | 226 | 693 | 8.3 |
| 215/60R16 | 95 | T | 221 | 664 | 8.3 |
| 215/60R17 | 96 | T | 221 | 690 | 8.3 |
| 215/65R16 | 98 | T | 221 | 686 | 8.3 |
| 225/50R17 | 94 | H | 233 | 658 | 8.3 |
| 225/50R18 | 95 | H | 233 | 683 | 8.3 |
| 225/55R18 | 98 | T | 233 | 705 | 8.3 |
| 225/60R17 | 99 | S | 228 | 702 | 8.8 |
| 225/60R18 | 100 | S | 228 | 727 | 8.8 |
| 225/65R17 | 102 | S | 228 | 724 | 8.8 |
| 235/45R18 | 94 | H | 236 | 669 | 8.3 |
| 235/55R18 | 100 | T | 245 | 715 | 8.3 |
| 235/60R18 | 103 | S | 240 | 739 | 8.8 |
| 245/40R18 | 93 | H | 240 | 8t0 | 8.8 |
| 245/45R18 | 96 | H | 240 | 780 | 8.8 |
| 245/45R20 | 93 | H | 240 | 720 | 8.8 |
| 245/45R20 | 101 | H | 240 | 71o | 8.8 |
